XM 600/001

XM 600/001 XMC Carrier Module for a CompactFlash Type 1 Card

XMC modules with one CompactFlash socket for a CompactFlash type 1 card. The CompactFlash card can be inserted and removed via the front panel. The module enables a quick and easy storage extension. The operating system support depends on the used host processor. The CompactFlash I/O signals are available via P15.

We offer a wide range of XMC modules.


Technical Description

  • XMC module, VITA 42.0
  • PCI 2.0 compliant, PCIe x1 and x2 (Gen 1 and Gen2) interface
  • Support for CompactFlash type 1 cards up to UDMA6
  • Card inserted and removed via front panel
  • Operating system support dependent on the host processor used
  • In 3 environmental classes available: standard (0°C .. 55°C), extended grade (-25°C .. +70°C), and (-40°C .. +85°C)
  • 2 years warranty

Order Information


XMC carrier module for CompactFlash

Technical Documentation

XM 600/001 Data Sheet
