TPMC371, TPMC372 Conduction Cooled 4 or 8 Port RS-232/422 Serial Interfaces

4 or 8 channel high performance serial interfaces with several standard combinations of RS232 and/or RS422 interfaces. The TPMC371 and TPMC372 conduction cooled PMC modules are designed for the use on carrier boards with stiffener bars and have an operating temperature range of -40°C to +85°C.

All RS232 channels support RxD, TxD, RTS, and CTS. Two channels of the TPMC371 and one channel of the TPMC372 have all signal lines for full modem support. All RS422 channels support RxD+/- and TxD+/-. Two channels of the TPMC371-11, and one channel of the TPMC372-11 offer also RTS+/- and CTS+/- signal lines. All modules have P14 I/O.

Each channel has 64 byte transmit and receive FIFOs. The FIFO trigger thresholds, and the baud rates are individually programmable: up to 921.6 kbps for RS232 channels, and 5.5296 Mbps for RS422 channels. All channels generate interrupts on PCI interrupt INTA. For fast interrupt source detection the UART provides a special global interrupt source register. All channels use transceivers with 15 KV ESD protection.

A wide range of drivers is available: Linux, Integrity, QNX, VxWorks and Windows. All drivers - except the Windows drivers - are supplied as C source code.

Non-standard configurations are available as factory build option. The modules are also available as TPMC46X with convection cooling.

ORDER NOW

TECHNISCHE BESCHREIBUNG

proimg1
  • PMC module without front panel, 32-bit/33MHz PCI interface, IEEE P1386.1 compliant, PCI 2.3 compliant, 3.3/5V Vio
  • Conduction-cooling, stiffener bars supported
  • TPMC371-10: 8 RS232 ports
    TPMC371-11: 8 RS422 ports
    TPMC371-12: 4 RS232 and 4 RS422 ports
    TPMC372-10: 4 RS232 ports
    TPMC372-11: 4 RS422 ports
    TPMC372-12: 2 RS232 and 2 RS422 ports
  • RS232 signals: TxD, RxD, RTS, and CTS,
    add. full modem support for one channel on the TPMC371 and for two on the TPMC372
  • RS422 signals: TxD+/- and RxD+/-,
    add. RTS+/- and CTS+/- signals available on one TPMC372-11 port, and on two TPMC371-11 ports,
    RxD+/- and CTS+/- with 120 W termination
  • P14 I/O
  • Exar XR17D154 or XR17D158 controller
  • 64 byte receive and 64 byte transmit FIFOs per channel
  • Transfer rates up to 5,5296 Mbit/s via RS-422 and 921.6 Kbit/s via EIA-232
  • 15 KV ESD protection
  • -40°C .. +85°C operating temperature range
  • Linux, Integrity, QNX, VxWorks, and Windows drivers available
  • 5 years warranty
