IC-GRA-XMCe

IC-GRA-XMCe GPU with AMD Radeon Graphics and 5 DisplayPort Outputs

High performance graphic controller based on the AMD Radeon E9170 GPU and up to DisplayPorts. The graphics controller combined up to 1.2 TLFOPs floating point performance and a large temperature range with a long term availability. The Radeon E9170 chipset is full compatible to OpenCL 2.0, OpenGL 4.5 and DirectX 12. 4 GB GDDR5 RAM enables a resolution of up to 5120 x 2880 pixel at 60 Hz. In addition, its dedicated Unified Video Decoder (UVD) and 4K HEVC/H.265 Video Encoding acceleration enables High Definition decode of H.264, VC-1, MPEG4, MPEG2 and MVC compressed video streams.

The module is available in two configurations: An XMC1.0 VITA 42 compliant board, with x8-lane PCI Express Gen2 interfaces and an XMC2.0 VITA 61 compliant board offering a x8-lane PCI Express Gen3 interface bus to the host.

The board is available in four versions. There is a standard 0°C to 55°C version, -20°C to +65°C, -40°C to +75°C rugged and -40°C to +85°C rugged operating temperature ranges.
